1. Enhanced treatment capacity
2.enlarging the sediment area
3.preventing rolling phenomena

Deaeration cell is provided to avoid solid particles attaching to bubbles and settling as parachute phenomena
The mineral-feeding pipe is beneath the liquid level lest air to be brought in while feeding.
The feeding casing is moved to a lower position and a receiving plate is equipped. Therefore, the fed slurry fall evenly and steadily, preventing rolling phenomena because of the residual pressure from feeding.
Inner overflow weir is equipped to have the pulp flow on pre-designed route, avoiding short circuit, enlarging the sediment area.
The pattern of the overflow weir is made into indented shape, eliminating part suction phenomena induced by unleveled overflow weir.
The rabble blade is changed from oblique lines to curves. So the discharging underflow has higher density, and treatment capacity is enhanced.

Parameter of updated high-efficiency thickener

Model	D of the tank(mm)	Depth of the tank (mm)	Sedimental area(m2)	Capacity(t/d)	Motor model	Motor  power(KW)	W of the tank(kg)	W(kg)
NZSG-2.5	2500	1850	4.9	5-22.4	Y90L-6	1.1	1000	2225
NZSG-3A	3000	1800	7	5-23.3	Y100L-6	1.5	1664	3168
NZSG-3	3600	1800	10.2	5-28.5	Y100L-6	1.5	2097	3640
NZSG-5	5000	2956	16	16-90	Y90L-4	1.5	5160	8031
NZSG-6	6000	2956	28.3	98	Y90L-4	1.5	5769	9200
NZSG-7	7000	3000	38.5	140	Y112M-6	2.2	8548	13361
NZSG-8	8000	3318	50.2	185	Y132S-6	3	12966	19289
NZSG-9	9000	3376	63	210	Y132S-6	3	15304	21960
NZSG-12	12000	3600	113	370	Y132S-6	3	25389	34823
NZSG-15	15000	4000	176	580	Y132M2-6	5.5	35800	58800
NZSG-18	18000	4400	255	960	YCT200-413	7.5	51000	75600
NZSG-20	20000	4400	315	1400	Y160M2-8	7.5	62000	83550

1. The specification of thickener can be designed on the requirements of customers.

2. The ability can rise 3-6 times if adding the flocculent.

3. The concrete structure can be used if the thickening diameter is more than 15 m.
